Product Description

• Specifications are provided for reference and are based on testing the ZT411printer using genuine Zebra supplies

• Results may vary in actual application settings or when using other-than-recommended Zebra supplies

• Zebra recommends always qualifying any application with thorough testing

• Features

• Printing

• Thermal transfer and direct thermal printing

• Thin film printhead with E3Element

• EnergyEqualizer for superior print quality

• 203 dpi print resolution (8 dots / mm)

• Print speed per second up to 14"(356 mm / second)

• Communication

• USB 2.0, high speed

• RS-232 Serial (RS-232C with DB9F connector; Configurable baud rate (2400 – 115,200kB), parity, and data bits. Stop bits at 1 or 2; Software (XON/XOFF), hardware (DTR/DSR or RTS/CTS) communication handshake protocols)

• 10/100 Ethernet: Supports networks internally integrated option that enables the use of Webview and Alert feature

• Bluetooth 4.1 (including Apple)

• Dual USB Host

• Media Support

• Dual media sensors transmissive and reflective

• 3” media supply hanger

• Auto calibration when printer is turned on or when printhead is closed

• Design

• Easy, side-loading metal print mechanism

• Tool-less printhead and platen replacement

• Metal media cover with enlarged clear viewing window

• Robust-gold user touch points indicating key adjustments

• Bi-fold media door decreasing overall operating space by 35%

• Operation

• 4.3-inch color touch display with intuitive menu for quick operation and settings management

• Bi-colored status LEDs for quick printer status

• ARM Cortex A7 processor

• 256 MB RAM memory (8 MB User Available)

• 512 MB Flash memory (64 MB User Available)

• Print Touch application

• Link-OS-enabled

• Auto-switching 100-240V power supply

• Energy Star Qualified

• Printhead element out detection 1

• Firmware

• Resident ZPL , ZPL II and EPLprogramming languages, selectable through software or front panel

• XML-Enabled Printing allows XML communications for barcode label printing eliminating license fees and printer server hardware while lowering customization and programming costs

Product Specification
