Jabil - TPE SEBS 1300 95A - Natural

Description

TPE-SEBS 1300 95A 3D printing filament is a Shore 95A elastomer that does not require drying to process and has excellent bed adhesion. It also enables printing ease. TPE-SEBS 1300 95A has better elasticity for applications that require flexibility and durability with the added benefit of excellent processing and no required drying. TPE-SEBS 1300 95A is slightly firmer than the 85A product to meet application requirements that call for flexibility but also need more rigidity to achieve the finished part performance. TPE-SEBS 1300 95A works on all open-platform desktop printers and can be run on Bowden Tube or direct drive configurations.

TPE-SEBS 1300 95A can be used for parts that need elastomeric properties that can bend, flex and stretch and has demonstrated a very high success rate in printing complex geometries. TPE-SEBS 1300 95A is similar to rubber and other thermoplastic elastomers in its properties. This material has a similar feel to harder grades of TPU and TPO products with less warp, more bed adhesion and fewer printing issues. TPE-SEBS 1300 95A is well suited to printing parts that require toughness and resilience as well as some flexibility and fatigue resistance. Some common applications include (but are not limited to): automotive interior trim components, packaging closures, covers and housings, drips, no slip feet for electronic and mechanical components, and gap seals. This material is nonhygroscopic and can be printed without drying.

Applications

Parts that require toughness and resilience as well as some flexibility and fatigue resistance along with elastomeric properties that can bend, flex and stretch
Complex geometries
Automotive interior trim components
Packaging closures, grips, gap seals
Covers and housings
No slip feet for electronic and mechanical components
Industries include
- Automotive
- Aerospace
- General Manufacturing

Advantages

High print success rates
Very low warpage and curl
No need for heated print bed or drying requirements
Shore 95A elastomer
High flexibility, bend and stretch
Non-hygroscopic, does not absorb moisture
Durable with repetitive motions
Less visible layer lines, less warp

Specifications

Printing Temperature:

The optimal printing range is 230° – 270°C

Bed Temperature:

A bed temperature of 50°C to 70°C will provide the best adhesion during printing.

Printing Speed:

Base printing speed of 25 mm/s
Infill speed of 15-25 mm/s
Wall speed of 15-25 mm/s
Initial layer speed of 15-25 mm/s

Diameter(s):

1.75mm and 2.85mm

Color(s):

Black

Natural

Cooling:

For best results, do not use a cooling fan while printing with TPE-SEBS.

Bed Adhesion:

Use a brim while printing on clean glass or a PEI sheet. No glue or extra adhesion method is necessary.

Other Tips:

If the material starts to short feed or bind up in the extruder, turn down the feeder wheel tension. It is recommended to start with as little tension as possible.
Using a PTFE or fluoropolymer-lined tubing will help with printing. Using this type of tube will allow the print temperature to be lower.

Information Sheets

Print Settings

Technical Data Sheets

Safety Data Sheets

Compare Materials

Jabil Powders


	UTS (Mpa) Orientation		Tensile Modulus (Mpa) Orientation		EaB (%) Orientation		Unnotched Impact Energy (J/m) Orientation	Notched Impact Energy (J/m) Orientation	Melt Temperature (°C)
Material	XY	Z	XY	Z	XY	z	XY	XY
	46	37	1790	1130	34	12	1010	48	182
	44	46	3390	3380	6	5	221	33	181
	53	51	1305	1349	41	21	1241	83	197

Jabil Filament


	UTS (MPa) Orientation	Tensile Modulus (MPa) Orientation	EaB (%) Orientation	Unnotched Impact Energy (J/m) Orientation	Notched Impact Energy (J/m) Orientation	Melt Temperature (°C)
Material	XY	XY	XY	XY	XY	XY
	35	2730	3	235	39	N/A
	49	2660	5	822	69	188
	66	6000	4	557	191	180
	56	1930	> 100	830	62	190
	88	10600	3	525	125	190
	61	2210	6	850	51	N/A
	45	1655	24	N/A	N/A	N/A
	39	1895	8	416	49	N/A
	47	3240	6	207	31	155
	6	19	900	N/A	N/A	163
	11	93	780	N/A	N/A	165
	19	13	4540	N/A	N/A	220
